Diferential autoblocant cu discuri MFactory pentru Nissan Skyline R32
Diferential autoblocant cu discuri MFactory pentru Nissan Skyline R32

Photos shown for illustration; shade and shape may differ slightly.

MFactory

MFactory Metal Plate LSD for Nissan Skyline R32

Sale price7.033,00 leiVAT included
Version: 1.0 way

Version
Supplier stock

The MFactory metal plate LSD locks the driven wheels through packs of friction plates, pressed by ramps and preload springs. Unlike a helical unit, it keeps locking when one wheel loses grip, which is why it is made for dedicated circuit, rally and drift cars.

Specifications

Brand MFactory
Code MF-TRS-10S14K-2 (1.0 way), MF-TRS-10S14KB-2 (1.5/2.0 way)
Type Metal plate limited slip differential
Material SAE 4320 steel, forged, double tempered, sub-zero treated and shot peened
Spider gears Cold forged, ceramic coated: 30% higher surface hardness
Preload Coil springs, around 85 lb as supplied; changed by the number of springs
Ramps 1.0 way 45/0 or 55/0 degrees
Ramps 1.5/2.0 way 45/22.5 or 45/45 degrees

Which cars it fits

  • Nissan Skyline R32 with RB20DET

What to check

  • 1.0 way locks on acceleration only. 1.5 way locks on acceleration and partly under engine braking. 2.0 way locks equally on and off throttle.
  • The 1.0/1.5 version ships set to 1.5 way and the 1.5/2.0 version ships set to 2.0 way, both with plates stacked for 100% lock. Switching ramps requires opening the differential.
  • Preload, ramp angle and lock percentage are adjustable without special tools, with the gearbox removed.
  • The plates wear: MFactory asks for their thickness to be checked at every service, minimum 1.58 mm. Replacement plates and preload springs are sold separately.
  • MFactory recommends: on rear-wheel drive, 1.0 or 1.5 way for road and circuit, 2.0 way for drifting.
